Precast Compound wall

With the increasing demand for boundary walls SCW has developed a completely advanced and economical solution using state of the art machinery. We design and manufacture precast compound wall systems for highways, distribution and warehouse centers, Villas, gated communities, residential complexes, private and public gardens, farms, estates, industries and other facilities. Since the introduction of our STARFENCE™ we have been at the forefront for the supply and installation of high quality and affordable precast compound walls. SCW designed walls adorn many large scale projects spread over hundreds of kilometers in different soil types across various states. With our experience, you’ll get the look and quality you want for your commercial, industrial, or residential projects.

Advantages of Precast Boundary wall:
  • Economical: Our precast boundary walls were less expensive when compared with conventional walls. Our quick-install process reduces the time, increases the productivity, quality and safety and thus the cost is reduced.
  • High quality and durability since our product is manufactured under controlled quality assured controlled environment. The manufacturing process is such that it is not weather-dependent, along with expertise in design.
  • Long lasting: Our precast reinforced concrete products stand for high dimensional accuracy, best quality and a long service life. Precast concrete allows increased accuracy and consistent placement of reinforcement when compared to insitu construction.
  • No limitations: Our experienced team will design, manufacture and install elements of the compound wall with highest quality that are tailor made to each individual project’s requirements. Any required design and height could be achieved.
  • No plastering required: SCW uses its state of the art machinery coupled with best practice methods for finishing the surfaces of our posts and panels which results in high finished end products requiring no plaster work.
  • Low maintenance: Once precast compound walls are installed, they don’t require much maintenance when compared with traditional cast-in-situ boundary walls.
  • Speed of installation: Speed is a critical hallmark of precast compound wall construction. By using the precast components we can complete a larger foot print in short period. Once precast installation starts, on-site construction and off-site manufacturing can be overlapped, thereby reducing overall site construction time. Our team of erectors will complete the installation in record time.
  • Reduced on site work: As the precast components were manufactured in factory, they arrive to site in ready to install condition thereby reducing the onsite work. Installation incorporates the latest in connection technology, and can proceed swiftly and safely in almost any weather by expert erectors.
  • Durability: The precast compound wall is highly durable resulting in reducing in routine maintenance costs.
  • Fire resistant: Precast concrete components can be designed to meet any degree of fire resistance required by building code or project specifications. Unlike other building materials, concrete is non-combustible and does not appreciably lose strength under elevated temperatures.
  • Reusable: The precast compound wall components were 80% reusable. The precast compound wall can be designed to be reused for future expansions.
  • No propping & Scaffolding: Most precast products are installed directly from the truck into position without the need for scaffolding
  • Aesthetic appeal: Precast compound wall offers endless design and aesthetic flexibility.
  • Safety: Safety can be improved onsite with less workers, equipment and material reducing site congestion.
Precast Compound wall

Precast Compound Wall Product Details

Post Width (mm) Panel Thickness (mm) Panel Length (mm) Height Options (mm)
100 30 2100 1220-1830
150 50 2100 1830-2750
200 60 2500 1830-3050
300 100 3000 1830-3050
